Reheater ignition exhaust silencer

category	Muffler model	Applicable boiler parameters			Specifications and characteristics of muffler
category	Muffler model	Exhaust pressure MPa	Temperature ℃	Exhaust pipe diameter mm	Displacement t/h	Total length H mm	Diameter Dn mm	Nozzle diameter d x s mm	Nozzle material	Silencing amount dB(A)
	MMR-40/2.26-540	2.26	540	133	40	1615	377	133×6	12Cr1MoV	39
	MMR-50/2.26-540			168	50	1758	412	168×7
	MMR-63/2.26-540			168	63	2030	412	168×7
	MMR-80/2.26-540			194	80	2130	520	194×7
	MMR-100/2.26-540			219	100	2093	612	219×8
	MMR-125/2.26-540			219	125	2180	612	219×8
	MMR-50/4.12-540	4.12	540	133	50	1667	377	133×7	12Cr1MoV	39
	MMR-63/4.12-540			133	63	1931	412	133×7
	MMR-80/4.12-540			168	80	2024	480	168×9
	MMR-125/4.12-540			194	125	2080	512	194×10
	MMR-160/4.12-540			219	160	2130	616	219×10
	MMR-200/4.12-540			245	200	2175	616	245×10
	MMR-250/4.12-540			273	250	2147	562	273×10

category	Muffler model	Applicable boiler parameters			Specifications and characteristics of muffler
category	Muffler model	Exhaust pressure MPa	Temperature ℃	Exhaust pipe diameter mm	Displacement t/h	Total length H mm	Diameter Dn mm	Nozzle diameter d x s mm	Nozzle material	Silencing amount dB(A)
	MMR-40/2.26-540	2.26	540	133	40	1615	377	133×6	12Cr1MoV	39
	MMR-50/2.26-540			168	50	1758	412	168×7
	MMR-63/2.26-540			168	63	2030	412	168×7
	MMR-80/2.26-540			194	80	2130	520	194×7
	MMR-100/2.26-540			219	100	2093	612	219×8
	MMR-125/2.26-540			219	125	2180	612	219×8
	MMR-50/4.12-540	4.12	540	133	50	1667	426	133×7	12Cr1MoV	39
	MMR-63/4.12-540				63	1931	426
	MMR-80/4.12-540				80	2024	426
	MMR-100/4.12-540			168	100	2072	480	168×9
	MMR-125/4.12-540			194	125	2080	516	194×10
	MMR-160/4.12-540			219	160	2130	616	219×10
	MMR-200/4.12-540			273	200	2175	616	273×10
	MMR-250/4.12-540			325	250	2181	716	325×10
